Cargo Transportation
Passenger Comfort Experience
FD00
FD00
FD00
FD00
FD00
FD00
Feature Showcase
Notes：● Standard - Not equipped ○ Optional
| Specification | Product name | FD00 | ||||
| Driving form | Rear wheel drive | |||||
| Driving style | Left rudder | |||||
| Cargo type | Flat | Steeplechase board | Rounded cargo | Corrugated cargo | Corrugated cargo | |
| Overall Dimension(mm) | 3498*1478*1800 | 3498*1478*1840 | 3498*1550*2040 | |||
| Gross Vehicle Weigh(kg) | 1480 | |||||
| Rated Load Weigh(kg) | 600 | 575 | 530 | 550 | 530 | |
| Number of Seats | 2 | |||||
| Maximum Speed(km/h) | 80 | |||||
| Maximum Gradeability(%) | 20 | |||||
| Cruising Range(km) | 120 | |||||
| Cargo Compartment Volume(m³) | / | / | 2.43 | 2.43 | 3.1 | |
| Battery information | Battery Type | Lithium iron phosphate | ||||
| Battery Brand | BANG HUA | |||||
| Battery Energy(kWh) | 12 | |||||
| AC Slow Charge(h) | ≤3(20%-100% Normal Temperature) | |||||
| DC Fast Charge(min) | / | |||||
| Motor information | Motor Type | Permanent magnet synchronization | ||||
| Motor Rated/Peak Powe(kw) | 13/20 | |||||
| Configuration | Steering assistance | Electric Power Steering | ||||
| Anti-lock braking system | ● | |||||
| Electronic Speed Controller | — | |||||
| Combination Mete | ● | |||||
| Pedestrian alerts | ● | |||||
| Reverse Monitor | ● | |||||
| Tire pressure monitoring | — | |||||
| Airbag | — | |||||
| Tire model | 165/70 R13 | |||||
| Manual air conditioning | ● | |||||
| Windows | Electric windows and doors | |||||
| Headlamps | LED headlights | |||||
| Automatic Low Beam | ● | |||||
| Daytime Running Lights | ● | |||||
